Adjustable Size Sandwich Production Line , Outside Wall Heat Preserving Mgo Board Machine
XD-D Full Automatic Building Moulding Construction Material Making Machinery
| Product Name | Building Moulding Board machine | Production capacity | 1500 Sheets |
| texture of material | steel | Warranty | 1 years |
| Automatic grade | Automatic | raw material | Mgo,mgcl,fiber glass mesh |
| Standard | CE | type | free standing |
1. Specification of Wall Board:
Length: unlimited.
Width: 60cm ---- 120cm (Adjustable)
Thickness: 1cm----15cm (Adjustable)
2. Machine Model:
According to different production capacity from 800 square meters to 3000 square
meters per eight hours wall board-making machine has different models for large-scale, middle-scale and small-scale.
All machine can produce board with same best-quality and specification board, only
has different production capacity.
For whole production line, we have common one, semi-automatic one and
full-automatic one, you can choose any kind of production line according to
your own condition.
3. Application of Wall Board:
The wall board produced by our machine will replace solid brick as indoor partition,
wall of steel structure and frame structure as well as wall of removable houses. Its
products can be used for outside wall heat-preserving in northeast area of China.
4. Board performance:
| 1 | Air-dry density | ≤ (Standard index)50kg/m2 | (Test Value) 30.0kg/ m2 |
| 2 | Drying shrinkage rate of the board | ≤0.08% | 0.015% |
| 3 | Anti-breaking load | ≥1400N | 5640N |
| 4 | Anti-impact | No breakage phenomenon such as cracking after three impacts | No breakage phenomenon such as cracking after three impacts |
| 5 | Thermal resistance of main section (T=90mm) | ≥1.35(m2.k)/w | ≥1.36(m2.k)/w |
| 6 | Thermal bridges area ratio | ≤8% | 2.22% |
| 7 | Sound reduction Index | | 36dB |
| 8 | Radioactivity | | None |
5. After-sale
After purchased the equipment, we will teach relevant technology for free, and will
go to your factory for installation and testing until you can produce the qualified
product by yourself. Our company will train 2-3 technical personnel for free until
he can get the skill. We will take responsibility for provide technical consultation
and following-up service for a long time, the equipment warranty period is one year
mgo board machine mgo board production line
