Fully Automatic EPS Sandwich Panel Production Line with Steel Structure
Fully automatic full-automation mgo board production line Instruction:
Fully automatic full-automation mgo board production line is our company new product developed successfully referring to advanced technology and experience from home and abroad.
It is the great invention of the exterior insulation board realizing industrial production, and we have applied for many national patents.
Fully automatic full-automation mgo board production line mainly including following parts:
1. Fully-auto mixing system
2. Automatic board-making machine
3. Automatic cutting saw
The whole production line including:
1. Double-axis mixing machine
2. Slurry machine
3. Foaming machine
4.60 type pulverizer(include dust collecting machine)
5. Screw type brine blender
6. Motor-driven board uploading machine
7. Automatic oil spreading machine
8. Full-automatic making machine
9. Speed-up repressing machine
10. Automatic cutter
11. Assembly line eight heads cutting machine
12. Automatic finished board stacking machine
13. Pulse type dust collecting machine
14. PLC automatic controlling system
15. Hydraulic type trolley
16. Sawdust griddle
| Sawdust griddle | PLC automatic controlling system |
| | |
Fully automatic full-automation mgo board production line Technical parameters:
1. Board standard width: 610mm and 1220mm
2. Machine dimension: 35m (L)* 1.76m (W)* 5.0m (H)
2. Installed power: 32kw
3. Board making specification: 2.45m (L)×1.3m(W)×20100mm (thickness)
4. Work efficiency: 1500m2/shift
