Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Brand Name : chuangxin

Model Number : Design as your request

Certification : ce

Place of Origin : CHINA

MOQ : 1 sets

Price : negotation

Supply Ability : 10 sets per month

Delivery Time : 30 days

Packaging Details : packing

Production capacity : 2000sqm

Type : mgo wall panel production line

Usage : making mgo wall panels

performance : water-proof,fire resistent,sound-prevesion

After-sales Service : Engineers available to service machinery overseas

Contact Now



Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift



decorative magnesium oxide board production line capacity 2000 sheets / shift Mgo wall panel making machine

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Introduction of wall panel machine:

1. Metering System
After accurate weighing Fly ash, cement and sand, then being stirred with water into a slurry.
2. Forced mixing system
The slurry is transported by conveyor to the slurry compulsory mixer, and mixing with polystyrene particles evenly. Finally the slurry is poured into the mold.
3. Steam curing system.
The mould will be driven into curing room by the ferry cart for curing

 Raw material proportion

Name Ratio
Cement 50-70%
Flyash 20%
Sand 8%
Polystyrene 2%

 wall panel making machine production line

No. Name Function Size (mm) Power(KW) Quantity(set)
1 Slurry mixer Mixing cement mortar of up and own materials 2300×820×820 3 2
2 Main mixer Mixing middle materials 2800×1500×1300 18.5 2
3 Crusher Crush and collection material after cutting 1960×880×1070 11 1
4 Duplex units feed in mould board Automatic feed-in mould board on the main formed units, no need by manual, can reduce labor, improve work speed. 4800×3100×2800 1.5 1
5 Main formed units It includes all of device of automatic feed-in cement mortar, fiber cloth, spreading, one-time forming and etc. 29000×1800×1500 11.5 1
6 oil brusher It can adhibit the PVC paper on the mould board by automatic. (Or brush the oil on the mould board) 2700×1600×800 1.1 1
7 Automatic tracking cutting device It can cut the product on production line when it’s wet, and it will not hurt the product and mould board, reduce the labor, low labor intensity . 4500×2000×1450 2.45 1
8 Hydraulic lifter of receiving board system It can load the formed board on the form rack, reduce labor, reduce hurting the board when by manual, and improve automatic. 2700×3800×1700 9.6 1
9 PLC Control system Control the production line automatic. 750×500×1800   1

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / ShiftDecorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / ShiftDecorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift
